FLYC-300

Lightweight Drone Mission Computer Powered by NVIDIA® Orin™ NX



Key Features:

  • Weighs only 297g for on-board installation
  • Up to 100 TOPS GPU by Jetson Orin NX
  • Supports multiple camera and sensor interfaces
  • 2x GbE and 2x USB3 for RGB/ Infrared/ hyperspectral cameras and lidar/ radar
  • 2x GMSL2 for HDR/ 3D cameras
  • Built-in UART and CAN to interact with flight controller
  • 1x M.2 2230 for storage and 4G/5G communication ready
  • Supports 4S-14S drone battery pack

Backplane Systems Technology is pleased to present Neousys FLYC-300. The Neousys FLYC-300 Series is an innovative, lightweight drone mission computer powered by the NVIDIA® Jetson Orin™ NX, designed for UAV and drone applications. Weighing a mere 297 grams, the FLYC-300 offers robust AI capabilities with up to 100 TOPS GPU performance, making it a powerful tool for autonomous navigation, obstacle avoidance, and object detection.

This mission computer supports a wide range of camera and sensor interfaces, including RGB, infrared, hyperspectral cameras, LiDAR, and 3D cameras. It features two GbE and two USB3 ports, as well as two GMSL2 ports for HDR and 3D cameras, ensuring versatile connectivity. Additionally, it includes built-in UART and CAN interfaces for seamless interaction with flight controllers, enhancing the drone’s stability and control.

The FLYC-300 is equipped with an M.2 2230 slot for storage and supports 4G/5G communication, facilitating real-time data transmission. Its wide voltage input range (4S to 14S battery packs) and XT30 DC-IN connector make it highly adaptable for various drone configurations. Recognized as a Platinum Honoree in the 2023 Military & Aerospace Electronics Innovators Awards, the FLYC-300 stands out for its exceptional performance and design.

This cutting-edge device transforms UAV systems by integrating advanced AI and vision technologies, improving operational effectiveness, reducing risks, and providing real-time information. Its lightweight and versatile design ensure it is ready for immediate deployment in diverse real-world applications, from environmental monitoring to infrastructure inspection.

Ordering Information

FLYC-300-JON8

Lightweight Drone Mission Computer with NVIDIA Orin™ NX 8GB and M.2 2230 Storage

FLYC-300-EC-JON8

Lightweight Drone Mission Computer with NVIDIA Orin™ NX 8GB, M.2 2230 Storage and Enclosure

FLYC-300-JON16

Lightweight Drone Mission Computer with NVIDIA Orin™ NX 16GB and M.2 2230 Storage

FLYC-300-EC-JON16

Lightweight Drone Mission Computer with NVIDIA Orin™ NX 16GB, M.2 2230 Storage and Enclosure

Optional Accessories

AccsyBx-FAN-FLYC-300

Fan assembly for FLYC-300

Cblkit-FLYC-300

Cblkit-FLYC-300

ThermalPad-90-FLYC-300

Thermal pad for FLYC-300, 90x90x0.5mm
