IBOX-600

NVIDIA® Jetson Orin NX/Orin Nano Fanless Intelligent Computer

Key Features:

  • ARM® Cortex®-A78AE 8-core Processor
  • 1024 NVIDIA® CUDA® Cores, 32 Tensor Cores
  • 3 x M.2 Slots for Wi-Fi / WWAN / SSD Expansion
  • 1 x CAN FD for Vehicle Connection
  • Selectable for RJ-45 / M12X Ethernet Connetors
  • JetPack™ SDK Includes Development Tools
  • Power Input 9~60VDC with Smart Power Management
  • Operating Temperature -25°C ~ 70°C
  • Patented Backup Battery Kit (UPS) for Emergencies

Backplane Systems Technology proudly presents the IBOX-600 Series – a rugged, fanless embedded system designed for edge AI computing. Powered by NVIDIA® Jetson Orin™ NX or Nano modules, the IBOX-600 delivers up to 100 TOPS of AI inference performance with 1024 CUDA cores and 32 Tensor cores. Its powerful ARM Cortex-A78AE CPU and onboard JetPack SDK enable rapid deployment of intelligent applications such as autonomous driving, smart transportation, and industrial machine vision.

Housed in a compact, durable aluminum chassis, the IBOX-600 features versatile I/O including 2x LAN (2.5GbE + GbE), HDMI 2.1, USB 3.2, RS-232/422/485, CAN FD, DIO, and 3x M.2/mPCIe slots for SSD, Wi-Fi, WWAN, and GPS expansion. It supports wide-range 9~60VDC input with over-voltage and current protection and includes a patented UPS backup battery for power failure resilience. Optional RJ-45 or M12 X-coded connectors ensure deployment flexibility in transport or industrial settings.

Certified to CE, FCC, EN50121-3-2, and MIL-STD-810G standards, and capable of operating from -25°C to 70°C, the IBOX-600 combines durability with top-tier AI capability. It’s the ideal platform for harsh-environment edge deployments where compact size, reliability, and performance matter most.

ORDERING INFORMATION
Model Number

IBOX-600

Description

NVIDIA® Jetson Orin NX / Nano SoM w/ 2x LAN/ 1x HDMI® / 1x CAN bus/ DC 9-60V/ Intelligent Computer

State of Origin

Made in Taiwan
