WISE-5236M

WISE-5236M (Web Inside, Smart Engine) functions as a control unit for use in remote logic control and monitoring in various industrial applications. WISE-5236M offers a user-friendly and intuitive web site interface that allows users to implement IF-THEN-ELSE control logic on controllers just a few clicks away; no programming is required.

•    Runs on Browsers, No Extra Software Tool is Required.
•    No More Programming, Web Pages Provided for Control Logic Editing.
•    IF-THEN-ELSE Logic Rules Execution Ability.
•    Support XV-Board.
•    Support DCON or Modbus RTU Slave Modules (Up to 32, COM3 and COM4 Can Connect to Max. 16 Modules Individually.).
•    Support Modbus TCP Slave Modules (Up to 16).
•    Timer and Schedule Functions Supported.
•    Data Logger and Data Files Send Back Function Supported.
•    Active I/O Sending Function for Real-Time Data Transfer.
•    CGI Command Sending and Receiving Function Supported for IP Camera and Network Device.
•    Support Line and Email Message Sending.
•    Support WeChat Message Sending.
•    Support Connection with IoT Cloud Platform (Microsoft Azure and IBM Bluemix).
•    Support IoTstar Cloud Management Software.

With the built-in IF-THEN-ELSE logic engine, WISE-5236M can execute the automation logic stably and efficiently, and it also provides mathematic operation, Schedule, and Email alarm message sending functions. WISE-5236M provides more supports in I/O module connection, I/O data logging, and IoT platform integration. It allows connection to XV-board, DCON I/O modules, and Modbus TCP/RTU Slave modules all together. The wide range of selection options enables flexibility in I/O module integration to meet the requirements from various applications.

WISE-5236M provides the MQTT client, it can directly connect to the major public IoT Cloud platform (such as Microsoft Azure or IBM Bluemix) and MQTT Broker. WISE-5236M also provides well-thought-out CGI command functions to integrate with IP cameras for the Access Control applications.

Based on the ability as I/O module connection ability, Intelligent logic control, Data logging, and various communication protocols supported (SNMP, MQTT, and Modbus TCP/RTU), WISE-5236M can help the IT/MIS/MES/SCADA system to manage the field side I/O modules and sensors efficiently in the application such as Unmanned Facility Room Monitoring, Intelligent Factory and Environment Monitoring. WISE-5236M is not just a Concentrator of I/O modules and Sensors; it is also a Gateway to transfer the sensor data to the IoT Cloud platform. All of these make WISE-5236M the best choice in the IoT Age.

WISE-5236M CR: IIoT Edge Controller (Metal Case) (RoHS)
