POC-751VTC

Intel® Core™ i3-N305 Ultra-compact In-Vehicle Computer with 4x PoE+, HDMI, SocketCAN, and mPCIe for WiFi/ 4G/ 5G Modules

Key Features:

Intel® Alder Lake Core™ i3-N305 processor 15W with 8 E-Cores
4x GbE PoE+ ports/ 4x USB3.2 Gen 2 with screw-lock
DP++/ HDMI 1.4b dual display outputs
2x isolated CAN 2.0 port, supporting SocketCAN in Linux
2x mPCIe for WiFi/ 4G/ 5G module with conduction-cooled heatsink
8-CH isolated DI & 8-CH isolated DO
8V – 35V DC input with built-in ignition power control
E-Mark certified and EN 50155 EMC compliant

Backplane Systems Technology is pleased to present Neousys POC-751VTC. The Neousys POC-751VTC is a cutting-edge ultra-compact in-vehicle computer designed to meet the demands of modern intelligent vehicle applications. Powered by the Intel® Alder Lake Core™ i3-N305 processor with eight energy-efficient cores, it delivers enhanced CPU performance, up to 1.3 times faster than its predecessor, the POC-551VTC. This robust computing platform supports up to 16GB of DDR5-4800 memory and features Intel’s UHD Graphics, enabling light AI applications through OpenVINO.

The POC-751VTC is engineered for in-vehicle environments, offering four GbE PoE+ ports capable of supplying 25W power to connected devices like IP cameras, making it ideal for mobile surveillance and passenger information systems. Its dual mini-PCIe slots, equipped with conduction-cooled heatsinks, allow for seamless installation of WiFi, 4G, or 5G modules, ensuring robust wireless communication capabilities.

Additionally, the system includes two isolated CAN 2.0 ports with SocketCAN support for efficient in-vehicle communications and a suite of isolated digital I/Os for precise sensor and actuator control. With its wide-range 8V to 35V DC input and built-in ignition power control, the POC-751VTC is perfectly suited for diverse vehicle deployments, making it a versatile and powerful solution for next-generation automotive applications.
