SI-334

AMD Ryzen™ Embedded V2000 Series Signage Player with AMD Vega GPU and Four HDMI

Key Features:

  • AMD Ryzen™ Embedded V2000 Series Processors
  • Vega GPU with up to 7 Compute Units
  • 4x HDMI 2.0 with Independent Audio Output Support
  • iSMART Intelligent Energy-Saving & Observer Remote Monitoring Technologies
  • Built-in CEC and Hardware EDID Emulation Functions with the Software Setting Mode
  • 2x DDR4-3200 SO-DIMM, Dual Channel, Max. 64GB
  • 1x M.2 B-Key for 5G or LTE Options
  • 1x M.2 E-Key for Wi-Fi, Bluetooth or Capture Card Options
  • 1x M.2 M-Key for Storage
  • Supports TPM 2.0 and Watchdog Timer
  • Slim and Segregated Flow Ventilation Design
SI-334 Signage Player with MBD334 w/ AMD Ryzen™ Embedded V2748 4.25GHz/2.9GHz; 2x 4GB DDR4-3200 SO-DIMM, M.2 128GB, 150W power adaptor (RoHS)
SI-334-46 Signage Player with MBD334 w/ AMD Ryzen™ Embedded V2546, 3.95GHz/3.0GHz; 2x 4GB DDR4-3200 SO-DIMM memory, M.2 128GB, 150W power adaptor
SI-MK3A Mounting bracket for SI-304/SI-122-N/SI-313/SI-313-N/SI-324/ SI-613/SI-623/SI-334 series
SI-1U-AD 1U Rackmount kit
HDMI Cable Holder SI-334 HDMI bracket kit
