TANK-801-BT

SKU 4189

Embedded System with Intel® Celeron®  J1900 2 GHz processor and Versatile 3 different backplane types

The TANK-801 Series embedded system is a fanless system for wide range temperature environments. It is powered by the Intel® Celeron® J1900 2.0GHz quad core processor and has 2.0 GB of DDR3L memory. The TANK-801 Series includes one DisplayPort, one DVI-I port, two PCIe GbE LAN, two USB 2.0 ports, two USB 3.0 ports and four COM ports.

  • Intel® Celeron®  J1900 2 GHz, 10W
  • 16-bit digital I/O, 8-bit input/8-bit output
  • 1 x DVI-I, 1 x DisplayPort
  • Various expansion type:  3A : One PCIe x1 + Two x PCI, 3B: Two PCIe x1 + One x PCI, 3C: Three x PCI
  •  Dual DC power input

TANK-801-BTi-J1/2G/3A-R11: Fanless embedded system with two PCI and one PCIe x 1 expansion , Intel Bay-Trail J1900 2GHz, TDP 10W, 2GB DDR3L pre-installed memory , 1 x DVI-I, 1 x DisplayPort , iRIS-2400 optional, 9V~36V DC; RoHs
TANK-801-BTi-J1/2G/3C-R11: Fanless embedded system with three PCI expansion , Intel Bay-Trail J1900 2GHz, TDP 10W, 2GB DDR3L pre-installed memory , 1 x DVI-I, 1 x DisplayPort , iRIS-2400 optional, 9V~36V DC; RoHs
TANK-801-BTi-J1/2G/3B-R11: Fanless embedded system with one PCI and two PCIe x 1 expansion , Intel Bay-Trail J1900 2GHz, TDP 10W, 2GB DDR3L pre-installed memory , 1 x DVI-I, 1 x DisplayPort , iRIS-2400 optional, 9V~36V DC,RoHs
