tSH-732i

SKU 4858

The tSH-700 module is a serial port sharer that provides a number of functions, including “Baud Rate Conversion”, “Modbus RTU/ASCII Conversion” and “Two Masters Share One Slave”. The built-in web server provides easy configuration interface, and no console commands are required.

  • Supports Baud Rate conversion application
  • Supports Modbus RTU/ASCII protocol conversion
  • Supports two masters sharing one slave port for tSH-73x Series only
  • Raw data mode for most query-response protocols
  • Built-in web server for easy configuration (HTTP)
  • Redundant power inputs: PoE (IEEE 802.3af, Class 1) and DC jack
  • Allows automatic RS-485 direction control
  • Tiny form-factor and low power consumption

tSH-732i CR: Tiny Serial Port Sharer with PoE, Power Isolation and 3 RS-232 Ports (RoHS)

  • ICP DAS
