8-Channel High Speed Thermocouple Measurement USB I/O Module



  • 8-Channel Analog Inputs
  • High Speed Thermocouple Measurement
  • USB 2.0 Full-Speed (12 Mbps)
  • No external power supply (USB Bus Powered)
  • LED Indicate the Power status
  • 3000 VDC intra-module isolation
  • Lockable and w/Ferrite core USB cable

Backplane Systems Technology is proud to introduce ICP DAS USB-4018HS. The USB-4018HS, an 8-channel high-speed thermocouple measurement USB I/O module, which is part of the innovative USB-4000 series. This module offers a cutting-edge solution for data acquisition, making it easier and quicker than ever before, especially compared to traditional PC-based cards like PCI, PC/104, and ISA cards.

The USB-4018HS supports a wide range of thermocouple types, including J, K, T, E, R, S, B, N, C, L, M, and LDIN43710. This versatility ensures it can be used in various applications requiring precise temperature measurements, such as SMD assembly manufacturing, pharmaceutical industry, food industry, and more. It features 8 analog input channels and boasts high-speed thermocouple measurement capabilities, providing accurate and reliable data for all kinds of automation applications.

One of the standout features of the USB-4018HS is its ease of use. It operates on USB 2.0 full-speed (12 Mbps), requires no external power supply as it is USB bus-powered, and includes an LED to indicate power status. The module also offers 3000 VDC intra-module isolation, ensuring safe and stable operation in different environments. Additionally, it comes with a lockable and ferrite core USB cable for secure connections.

The USB-4018HS simplifies data acquisition through its plug-and-play functionality and the user-friendly USB-4000 series Utility, allowing users to configure and test the module directly without any coding. This makes it an ideal choice for industries that require precise temperature measurement and monitoring.

In conclusion, the ICP DAS USB-4018HS is a high-performance, versatile, and user-friendly solution for all temperature measurement needs, setting a new standard in data acquisition technology.


Ordering Information

USB-4018HS     CR  8-Channel High Speed Thermocouple Measurement USB I/O Module with 3000 VDC intramodule isolation (RoHS)
Includes 1.5M USB Cable (CA-USB-AM1-L015)
